FPCD1806H FPC Tag
Air interface protocol
ISO/IEC 14443A ISO15693/ISO18000-3
Operational frequency
13.56MHz
Tag dimensions
18 * 6mm
Mechanical Specification
Base Material
FPC
Quantity
About 0.1g / Piece
Shell Color
Yellow
Installation method
Adhesive, No Adhesive
Tag dimensions
18 * 6mm
Electrical Specification
Air Interface Protocol
ISO/IEC 14443A ISO15693/ISO18000-3
Frequency
13.56MHz
IC type
NTG 213
Memory
1K bytes EEPROM Read/Write
IC Life
100,000 Times
Data Retention
10 Years
Reading Range
3~5cm
Other Parameters
Operating temperature
-30°C ~ 85°C
Storage Temperature
-40°C ~ 100°C
Sealing Level
IP68
Certification
RoHS
Application Area
Event Management
RFID tags or tickets help to automate the registration and check-in process. RFID technology makes the check-in process much faster and more convenient for customers.
Access Control
In access control scenarios, RFID tags or cards can hold access credential information and when placed near a compatible reader or antenna, transmit the credential…
