QY-D20 International Standard 1 D/2D Barcode RFID Handheld Terminal

CPU
Octa-core，2.0 GHz

Memory
RAM:2GB ROM:16GB;
RAM:3GB ROM:32GB;
RAM:4GB ROM: 64GB(optional)

GET A QUOTE / DATASHEET

Product Features

•The 4-inch Screen Provides Extra Space for information, While Full Keypad Shortcut Support Allows Better and More Convenient Operation.
•Android11.0 System, Flagship Eight Core 2.0 GHz Processor, Super Performance Configuration.
•Optimized Loudspeaker Designed, and The Noisy Environment Can Be Heard Very Clearly.
•Professional Scan Engine, a Millisecond Response, Supporting Bending, Fold, Dirt Loss, Screen Code, etc.
•Efficient Voice Intercom, Communicating at Any Time, More Efficient
•Waterproof Structure Design, Dripping Water Does Not Enter

Performance Parameter

Model
QY-D20

O.S.
Android 11.0

CPU
Octa Core, 2.0 GHz

Memory
RAM:2GB ROM:16GB;
RAM:3GB ROM:32GB;
RAM:4GB ROM: 64GB(optional)

Extended Memory
Micro-SD card, Up to 256GB

Basic Specifications

Dimensions
164.5*68.6*17.5mm

Weight
279g (Battery Included)

Display
4 Inch Display (480*800pixel)

Touch Screen
Ultra Sensitive Capacitive Touch Panel, Support Multi-Touch, Works With Gloves and Wet Fingers.

Main Battery
3.85V 5000mAh Rechargeable Lithium Battery

Audio
Microphone, Speaker, Receiver

Buttons
Front 21-key Digital Main Keyboard, Power key, Volume +,- key Custom key, Scan key*2

Camera
Front 2MP，Rear 13MP With Flash

Scanning
Professional Scan Engine; Support International Standard 1 D/2D Barcode; Support Barcode Displayed on Screen and Colored Barcode;

Sensors
Light + Accelerator + Proximity

Slots
Micro SD/TFx1,Nano-SIMx2 Can Support 256GB Expansion

Network Connection

WWAN
4G/3G/2G Dual-SIM, Dual-Standby

Bluetooth
BT5.0 + BR/EDR +BLE

Wi-Fi
2.4G/5G, IEEE 802.11 a/b/g/n/ac/d/e/h/i/k/r/v/w, Roaming: 802.11 r /OKC/ PMKID Caching, 802.11 ax Ready

Positioning
GPS、A-GPS、BeiDou、GLONASS 、Galileo

Environment

Operating Temp
-20°C to 60°C

Storage Temp
-40°C to 70°C

Humidity
5%RH~95%RH(No Condensation)

Drop Specification
Multiple 1.2 m Drops to Concrete at Room Temperature

Sealing
IP67, Waterproof Structure Design

ESD
+/-15kv Air; +/-8kv Contact

Rear Camera

Functions
Flash light, Auto-focus, Video

Pixels
13MP

Front Camera

Functions
Fixed-Focus

Pixels
2MP

Scan Engine

Scan Angels Tilt
360°

Scan Angels Pitch
±60°

Scan Angels Skew
±60°



Barcodes Support
Linear: Codabar 11, Code 128, Code 2 of 5, Code 39, Code 93 and 93i, EAN/JAN-13, EAN/JAN 8, IATA Code 2 of 5 Interleaved 2 of 5, Matrix 2 of 5, MSl, GS1 Databar, UPC-A, UPC E, UPC-NEAN-13 with Extended Coupon Code, Coupon GS1 Code 32(PARAF), EAN-UCC Emulation, GS1 Data Bar.
2D Stacked: Codablock A, Codablock F, PDF417, MicroPDF417.
2D Matrix: Aztec Code, Data Matrix, MaxiCode, QR Code, Chinese Sensible(Han Xin), Grid Matrix, Dot Code.
Postal: Australian Post, British Post, Canadian Post, China Post, Japanese Post, Korea Post, Netherlands Post, Planet Code, Postnet.

RFlD (HF)

RFID
Read/Write (HF)

Protocol
ReadableISO15693、ISO14443 A/B/F

Frequency
13.56MHz

Mode
Card Emulation、Peer-to-Peer、Reader

Reading Range
Read Distance 3-8cm, The Distance is Related to The Tag

GPS Positioning

Support Mode
GPS,A-GPS,BeiDou, GLONASS,Galileo

Frequency
GPS{L1 1.575GHz C/A Code), BeiDou(B1 1.56GHz), GLONASS{L11.602GHz), Galileo(E1 1.589 GHz/E2 1.561 GHz)

Cold Start Time
Less Than 40s

Max Channel
31 Channel

Sensitivity
-130dB(SNR Value 40dBHz)

Precision
5-10 Meters (Open Space)

Wireless LAN

Protocol
IEEE 802.11 a/b/g/n/ac/d/e/h/i/k/r/v/w Protocol (2.4G/5G Dual Band WIFI), IEEE 802.11ax Ready

Frequency
2.4G 5G

Working Channels
CH1~CH13,CH34~CH140,CH149~CH165(Depends on Area)

Security and Encryption
WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise 192-bit Mode (GCMP-256) – EAP-TLS; Enhanced Open (OWE)

Fast roaming
PMKID Caching; Cisco CCKM; 802.11 r(Over-the-Air); OKC, Can Set WiFi Roaming Threshold

WirelessWAN

WAN Mode
Dual-SIM, Dual-Standby







Worldwide Radio Frequency Band
TD-L TE(B34/B38/B39/B40/B41)
FDD-L TE(B1/B2/B3/B4/B5/ B7/B8/B12/B13/ B 17 /B20/B28A/B28B)
WCDMA(B1/B2/B4/B5/B8)
TD-SCDMA(B34/B39)
CDMA2000 1x EV-DO Rev A BCO (800MHz)
CDMA1x
GSM/EDGE/GPRS(850/900/1800/1900)

Bluetooth

Support Mode
BT5.0+BR/EDR+BLE

Connection Distance
More than 10 m

Accessories Type

Standard Accessories
Adapter*1, Type-C cable*1, Battery*1, Hand Strap*1, Instructions &Security Information & Warranty Card*1

Optional Accessory
Single Charging Cradle(1 Terminal, 1 Ba廿ery Charging), 4-slot Charging Cradle, 4-Slot Battery Charging Cradle, Pistol Grip, Hand Strap, Boot Case

Accessories Picture

QY-D20-Accessories Picture
